Acrolite
1M Light Aircraft
Name :
Acrolite
Model:
1M
Type:
Single Place light sport high
wing monoplane, strut braced.
Construction: Welded
steel tube fuselage, riveted aluminum tube tail group,
full sheeted box spar wing.
Aircraft Physical
Specifications
| Engine |
40 hp Rotax 440 |
50 hp Rotax 503 |
65 hp Rotax 582 |
| Reduction |
2.58 to 1 |
2.58 to 1 |
2.58 to 1 |
| Propeller |
58 x 42 |
60 x 47 |
63 x 51 |
| Airfoil |
GA30U-412 |
|
|
| Wingspan |
23 ft. |
|
|
| Wing area |
92 sq. ft. |
|
|
| Aspect ratio |
5.75 to 1 |
|
|
| Length |
16.2 ft. |
|
|
| Height |
6 ft. |
|
|
| Fuel capacity |
8 gal U.S. |
|
|
| Wheel & tire size |
500 X 5 |
|
|
| Empty weight |
450 lbs. |
450 lbs. |
450 lbs. |
| Gross weight |
750 lbs. |
750 lbs. |
750 lbs. |
| Span loading |
32.6.0 lb./ft. |
32.6 lb./ft. |
32.6 lb./ft. |
| Wing loading |
8.2 lb./sq. ft. |
8.2 lb./sq. ft. |
8.2 lb./sq. ft. |
| Power loading |
18.7 lb/bhp. |
14 lb/bhp. |
10.8 lb/bhp. |
Aircraft Performance
Specifications (computer projected)
| Power off stall speed |
44 mph. |
44 mph. |
|
| Power on stall speed |
40 mph. |
40 mph. |
|
| Landing speed |
55 mph. |
55 mph. |
|
| Maneuvering speed |
89 mph. |
|
|
| Maximum level speed |
97 mph. |
109 mph. |
119 mph. |
| Never exceed speed |
150 mph. |
|
|
| Cruise speed |
82 mph @ 5000
rpm. |
92 mph @ 5600
rpm. |
101 mph. |
| Best glide speed |
64 mph. |
|
|
| Best rate of climb |
679 fpm. |
943 fpm. |
1347 fpm. |
| Best climb rate speed |
70 mph. |
70 mph. |
80 mph |
| Range |
250 sm. |
|
|
| Take off distance |
600 ft. |
550 ft. |
500 ft. |
| Landing distance |
500 ft. |
|
|
|
